中冷器总成21M-03-21350适用于PC650-8挖掘机，黑龙江配件供应

中冷器总成21M-03-21350适用于PC650-8挖掘机，黑龙江配件供应

RADIATOR GUARD AND MOUNTING

ITEM PART NO. DESCRIPTION

1 15254571 GRILLE-BOTTOM

2 15254572 GRILLE-TOP

3 271605 BOLT

4 179889 BOLT

5 9270000 WASHER-HARDENED

6 179883 BOLT

7 9176228 WASHER-HARDENED

MUDGUARDS

ITEM PART NO. DESCRIPTION

1 15309981 MUDFLAP

2 15302966 PLATE-CLAMPING

3 15309991 PLATE-BACKING

4 179883 BOLT

5 179885 BOLT

6 103329 LOCKWASHER

7 120378 NUT

8 9267949 WASHER-HARDENED

9 15246422 MUDFLAP-LH

10 15302964 BRACKET-LH

11 15312422 MUD FLAP

12 15313089 PLATE-CLAMPING

13 15313088 MUD FLAP-LH

14 15302963 MUD FLAP-RH

15 15309984 MUDFLAP LH REAR

16 179881 BOLT

17 179890 BOLT

18 15309985 PLATE-BACKING

19 15312421 PLATE-BACKING

ENGINE AND MOUNTING

ITEM PART NO. DESCRIPTION

1 15267514 FILTER-LUBE BYPASS

2 15267633 FILTER-FUEL

3 15266845 FILTER WF-15DCA4

4 15267513 FILTER-LUBE OIL

5 15273590 FAN BELT

6 223464 BOLT

7 15020053 WASHER

8 9269110 MOUNTING-SHOCK

9 223458 BOLT

10 9176228 WASHER-HARDENED

11 9250715 WASHER-HARDENED

12 9419493 LOCKNUT

13 223452 BOLT

14 9068286 BRACKET-ENG MTG REAR

15 15246912 FLANGE-COUPLING

16 9409907 BOLT

17 9423067 BOLT

18 9060202 WASHER-HARDENED

19 15228210 COUPLING-DRIVE

20 179885 BOLT

21 186729 BOLT

22 15245965 TUBE ASSY

23 15245968 TUBE ASSY

24 142269 BUSHING-REDUCER

25 144218 BUSHING

26 271619 BOLT

27 15019632 SUPPORT

28 454993 BOLT

29 103329 LOCKWASHER

30 15231571 FAN BLADE

31 9139801 CLAMP

32 15249612 HOSE-DIPSTICK

33 9266565 HOSE

34 181370 BOLT
