供应特雷克斯TEREX矿用自卸车TR50配件齿轮9228704
AIR CLEANER
ITEM PART NO. DESCRIPTION
1 15254860 AIR CLEANER
2 15270188 ELEMENT-MAIN
3 15270189 ELEMENT-SAFETY
4 15270190 LOVER ASSY
5 15270191 LATCH
6 15270192 VALVE-VACUATOR
AIR CLEANER PIPES AND HOSES
ITEM PART NO. DESCRIPTION
1 15254841 PLENUM CHAMBER
2 15254842 TUBE-LH
3 15254843 TUBE-RH
4 9267949 WASHER-HARDENED
5 9004851 CAP ASSY
6 15253938 HOSE-HUMP
7 9197976 HOSE-HUMP
8 9229246 CLAMP
9 9071447 CLAMP
10 179860 BOLT
11 15235949 GAUGE-AIR RESTRICT
12 179883 BOLT
POWER TAKEOFF-ENG
ITEM PART NO. DESCRIPTION
1 15257485 P.T.O. ASSEMBLY
2 15257459 HOUSING ASSY-MACHD
3 784079 PIN
4 454864 BOLT
5 9274893 GEAR-DRIVEN
6 9195847 GEAR-DRIVE
7 15246910 SHAFT-DRIVE PTO
8 9195842 GASKET
9 907696 BEARING
10 954528 BEARING
11 9414895 RING-SNAP
12 9004541 SEAL
13 9004540 SEAL
14 444625 PLUG
15 444637 PLUG
16 179826 BOLT
17 103320 LOCKWASHER
18 15300851 YOKE-PTO
19 9071870 WASHER-HARDENED
20 9269703 NUT LOCK
21 15247042 BREATHER ASSY
22 6750967 CAP-BREATHER
23 103328 LOCKWASHER
24 187396 COUPLING
25 144218 BUSHING
26 433142 BOLT
27 179860 BOLT
TRANSMISSION MOUNTING
ITEM PART NO. DESCRIPTION
1 271621 BOLT
2 9012026 SPACER（0.25 IN）
3 9012544 MOUNTING
4 9355771 NUT
5 9136532 NIPPLE
6 271568 BOLT
7 2337379 CLAMP
8 9141843 HOSE
9 271562 BOLT
10 103331 LOCKWASHER
11 9003673 WASHER
12 9003685 BUSHING
13 108580 LOCKWASHER
14 179839 BOLT
15 223453 BOLT
16 103332 LOCKWASHER
17 9195340 CAP-FILLER
18 9268885 LOCKWASHER
19 9066677 RING
20 15257170 ADAPTOR
